GB
20
Installation material
a) Washer M6 (52x)
b) Nut (38x)
c) Hex screw (52x)
d) Allen screw (6x)
n) Lock bolt (2x)
u) Washer M5 (6x)
v) Retaining
clip
Tools
r) Open-ended wrench, size 10/13
s) Ring wrench, size 10/24
t) Allen key, size 4mm
5. Intended use
The bench-type circular saw is designed for the
slitting and cross-cutting (only with the cross
stop) of all types of timber commensurate with
the machine’s size. The equipment is not to be
used for cutting any type of round wood.
The equipment may only be used for the tasks it
is designed to handle. Any other use is deemed
to be a case of misuse. The user/operator and
not the manufacturer will be liable for any
damage or injuries of any kind caused as a
result of this.
Please note that our equipment has not been
designed for use in commercial, trade or
industrial applications. Our warranty will be
voided if the equipment is used in commercial,
trade or industrial businesses or for equivalent
purposes.
The equipment is to be operated only with
suitable saw blades (saw blades made of HM
or CV) It is prohibited to use any type of HSS
saw blade and cutting-off wheel. To use the
equipment properly you must also observe the
safety information, the assembly instructions
and the operating instructions to be found in
these operating instructions.
All persons who use and service the equipment
have to be acquainted with these operating
instructions and must be informed about the
equipment’s potential hazards. It is also
imperative to observe the accident prevention
regulations in force in your area. The same
applies for the general rules of health and
safety at work. The manufacturer will not be
liable for any changes made to the equipment
nor for any damage resulting from such
changes. Even when the equipment is used as
prescribed it is still impossible to eliminate
certain residual risk factors. The following
hazards may arise in connection with the
equipment’s construction and design:
■ Contact with the saw blade in the
uncovered saw zone.
■ Reaching into the running saw blade (cut
injuries).
■ Kick-back of workpieces and parts of
workpieces.
■ Saw blade fracturing.
■ Catapulting of faulty carbide tips from the
saw blade.
■ Damage to hearing if ear-muffs are not used
as necessary.
■ Harmful emissions of wood dust when used
in closed rooms.
6. Technical data
AC motor 230-240 V ~ 50Hz
Power P S6 40% 1700 W
Idle speed n
0
6500 min -1
Carbide saw blade Ø 250 x Ø 30
Number of teeth 24/48
Bench size 610 x 445 mm
Table width extension, left/right 608 x 250 mm
Table length extension, rear 435 x 320 mm
Cutting height max. 73 mm / 90°
63 mm / 45°
Infinite height adjustment 0 - 73 mm
Infinitely adjustable saw blade angle 0° - 45°
Dust extraction connector approx. diameter
36 mm
Weight with base frame, incl. all removable
parts approx. 28.5 kg
